An event-driven, coroutine-based HTTP/1.1 and HTTP/2 server library for C++20, built on a multi-threaded reactor — epoll on Linux, IOCP on Windows (both natively supported).
This is a from-scratch redesign of the original libnhttp: same feature set and design philosophy, none of the old implementation carried forward. The design rationale, what changed and why, and the historical bugs some of this code deliberately guards against are documented in CONCEPTS.md, USAGE.md, and docs/protocol-extensibility.md.
Table of contents
- License
- Requirements
- Building
- Quickstart example
- Architecture overview
- Static file serving
- Virtual hosting
- Routing (the
routermodule) - Plugin system
- WebSocket
- TLS/SSL
- Reverse proxy
- HTTP/2
- Windows
- Benchmarks
- Design documents
MIT License
Copyright (c) 2021 Jay (jay94ks@gmail.com)
Permission is hereby granted, free of charge, to any person obtaining a copy
of this software and associated documentation files (the "Software"), to deal
in the Software without restriction, including without limitation the rights
to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
copies of the Software, and to permit persons to whom the Software is
furnished to do so, subject to the following conditions:
The above copyright notice and this permission notice shall be included in all
copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
SOFTWARE.
No third-party code is vendored in this rewrite — the WebSocket handshake's SHA-1/base64 are
self-contained implementations under the same license (see src/ws/sha1.cpp).
- Linux (epoll-based reactor) or Windows (IOCP-based reactor)
- GCC ≥ 11, Clang ≥ 14, or MSVC ≥ 19.29 (VS 2019 16.10) — C++20 coroutines
- CMake ≥ 3.20
- OpenSSL (for TLS/SSL support; see
NHTTP_ENABLE_TLSbelow to disable) — on Windows this means an MSVC-linkable OpenSSL dev package (e.g. via vcpkg), not just theopensslCLI
cmake -S . -B build -G Ninja -DCMAKE_BUILD_TYPE=Debug
cmake --build build
ctest --test-dir build --output-on-failureBuild options (-D<option>=ON|OFF at configure time):
| Option | Default | Meaning |
|---|---|---|
NHTTP_BUILD_TESTS |
ON |
Build the Catch2 test suite |
NHTTP_BUILD_EXAMPLES |
ON |
Build examples/nhttpd |
NHTTP_WARNINGS_AS_ERRORS |
ON |
Treat compiler warnings as errors |
NHTTP_ENABLE_TLS |
ON |
Build TLS/SSL support (requires OpenSSL) |
The library builds warning-free under -Wall -Wextra -Wpedantic (plus several more, see
cmake/CompilerWarnings.cmake) — this is a hard requirement, not aspirational. On MSVC the
closest equivalent is used instead (/W4 /permissive-, no 1:1 match for every GCC/Clang flag).
On Windows, from a native shell with the MSVC toolchain on PATH (e.g. after running
vcvars64.bat), the same three commands work unchanged:
cmake -S . -B build -G Ninja -DCMAKE_BUILD_TYPE=Debug
cmake --build build
ctest --test-dir build --output-on-failure#include "nhttp/server/listener.hpp"
#include "nhttp/server/extensions/overlay.hpp"
#include "nhttp/router/router.hpp"
using namespace nhttp::server;
using namespace nhttp::router;
using namespace nhttp::platform;
int main() {
listener srv;
// serve static files from "." (falls back to index.html for directories).
srv.extends(overlay_of(".", "index.html", srv.blocking_pool()));
// a small REST API.
auto api = make_router();
api->get("whoami", target_by([](request&) {
return make_response("I'm jay.");
}));
api->get("/:user", target_by([](request& req) {
return make_response(route_of(req).captures.at(":user") + " is ...");
}));
srv.extends(api);
if (!srv.listen(endpoint(ip_address::loopback_v4(), 8080)))
return 1;
srv.run(); // blocks; call srv.stop() (e.g. from a handler) to return
return 0;
}See examples/nhttpd/main.cpp for a fuller example (static files + a REST API with route
groups, parameter predicates, and a WebSocket echo endpoint), and USAGE.md for more
call-site patterns.
src/platform/ portable address/socket/reactor/file_info API, backed by posix/ (epoll) or
win32/ (IOCP) — never both in one build
src/async/ task<T> (coroutines), io_context (the reactor), io_context_pool
(SO_REUSEPORT multi-threading, or an explicit round-robin fallback where
SO_REUSEPORT isn't available), thread_pool (blocking-work offload)
src/io/ async stream interface + memory/file/range/socket streams
src/protocol/ header/method/status/mime/date/query-string/resource parsing,
chunked transfer codec, multipart/form-data streaming parser
src/server/ listener, HTTP/1.1 connection and HTTP/2 connection_h2 (one coroutine each,
no state-machine enum), request/response, the extension registry,
vhost/vpath/overlay/single_file/reverse_proxy
src/router/ the REST router: path trie, fluent registration DSL, middleware, grouping
src/plugin/ server-lifecycle + per-request-scope hooks for cross-cutting functionality
(e.g. a DB connection pool), built on router's middleware, not a separate one
src/ws/ WebSocket handshake + real RFC 6455 frame I/O
src/http2/ HPACK (RFC 7541) + frame codec (RFC 9113)
A listener runs one io_context per worker thread. On platforms with SO_REUSEPORT (Linux),
each worker binds its own socket per listening endpoint and the kernel load-balances accepted
connections across threads; where that's unavailable (Windows has no equivalent), one worker
accepts and explicitly round-robins each new connection onto another. Either way, a connection
stays on whichever worker ends up owning it for its entire lifetime.
srv.extends(overlay_of("/var/www", "index.html", srv.blocking_pool()));Conditional GET (ETag/If-None-Match/If-Modified-Since) and byte-Range requests
(206 Partial Content) work automatically, with no handler code — the same engine backs both
directory serving (overlay) and single-fixed-file serving (single_file).
Note: a
router(or any extension built onvpath) mounted at"/"accepts every request in its cheapwants()check, so give a static overlay (or anything else that should get first refusal) a lower priority number than the router — see the priority argument onoverlay's constructor andexamples/nhttpd/main.cppfor a worked example. This is covered in more depth inCLAUDE.md's architecture-decisions log.
auto example_com = vhost_for("www.example.com"); // exact hostname, a regex, or a predicate
example_com->extends(overlay_of("./example.com", "index.html", srv.blocking_pool()));
srv.extends(example_com);auto router = make_router();
router->get("whoami", target_by([](request&) { return make_response("I'm jay."); }));
router->group([](facade_ptr inner) {
inner->get(":user/profile", target_by([](request& req) {
return make_response(route_of(req).captures.at(":user") + " is ...");
}));
inner->post(":user/set", target_by([](request& req) -> async::task<response> {
std::string body;
co_await req.body->read_all(body);
co_return make_response(std::move(body));
}));
inner->param(":user", [](std::string_view name) {
return name == "jay" || name == "kay";
});
})->prepend(std::make_shared<my_logging_middleware>());
srv.extends(router);Matching priority per path segment is static child → deepest-matching parameter child →
wildcard — this exact tie-break was the subject of a real, previously-shipped bug, and is
locked in by a dedicated regression test (tests/unit/test_router_route.cpp).
For cross-cutting functionality that needs both a place to hook the server's own lifecycle
(e.g. a database connection pool, created once at startup and torn down once at shutdown) and a
before/after hook scoped to just the specific routes that use it, with access to that request's
own tag storage to hand the route a resource — implement nhttp::plugin::plugin and attach it two
ways: to the server (for on_init/on_deinit) via plugin_manager, and to specific routes (for
on_begin/on_end) via plugin_scope, the same router::middleware/prepend() mechanism used
for any other middleware:
struct db_connection_tag { mysql_connection conn; };
class mysql_plugin final : public plugin::plugin {
public:
async::task<void> on_init(listener&, async::io_context& ctx) override {
pool_ = co_await mysql_pool::connect(ctx, "db.internal", ...);
}
async::task<void> on_begin(request& req) override {
req.tags.ensure<db_connection_tag>().conn = co_await pool_->acquire();
}
async::task<void> on_end(request& req) override {
co_await pool_->release(std::move(req.tags.get<db_connection_tag>()->conn));
}
private:
std::shared_ptr<mysql_pool> pool_;
};
auto mysql = std::make_shared<mysql_plugin>();
plugin::plugin_manager plugins;
plugins.attach(mysql);
router->group([](facade_ptr inner) {
inner->get(":user/profile", target_by([](request& req) {
auto& conn = req.tags.get<db_connection_tag>()->conn; // set by mysql_plugin::on_begin
return make_response(query_profile(conn, route_of(req).captures.at(":user")));
}));
})->prepend(std::make_shared<plugin::plugin_scope>(mysql));
srv.extends(router);
plugins.init_all(srv);
srv.run(); // blocks until stop()
plugins.deinit_all(srv);on_end always runs to match on_begin, even if the wrapped handler threw, so a plugin can rely
on it to release whatever on_begin acquired regardless of how the handler finished. Unlike
server::extension (tried for every request at the listener level), on_begin/on_end only
wrap routes explicitly opted in via plugin_scope — a plugin with no server-wide setup can skip
on_init/on_deinit entirely, and one with no per-request state can skip on_begin/on_end.
srv.extends(websocket_endpoint_for("/ws", [](std::shared_ptr<ws::ws_connection> ws) -> async::task<void> {
for (;;) {
auto msg = co_await ws->receive();
if (!msg) co_return;
co_await ws->send_text(msg->data); // echo
}
}));Full RFC 6455 frame I/O (masking, fragmentation, ping/pong, close handshake) — not just the handshake.
srv.listen_tls(endpoint(ip_address::loopback_v4(), 8443), "cert.pem", "key.pem");Requires OpenSSL and NHTTP_ENABLE_TLS (on by default). listen_tls mirrors listen's
per-worker SO_REUSEPORT binding, so a TLS endpoint gets the same multi-threaded load
distribution as plain HTTP. Internally, tls_stream implements the same io::stream interface
as socket_stream — it drives OpenSSL against a pair of in-memory BIOs and pumps ciphertext to
and from the connection's own async stream, so the TLS handshake and every subsequent read/write
are ordinary co_awaits and never block a reactor thread. Everything above the transport layer
(routing, extensions, overlay, WebSocket, etc.) works identically over TLS with no code
changes — see examples/nhttpd/main.cpp for a listener that serves both plain HTTP and HTTPS.
using nhttp::server::upstream;
std::vector<upstream> upstreams{
upstream(endpoint(ip_address::loopback_v4(), 9001)),
upstream(endpoint(ip_address::loopback_v4(), 9002)),
};
srv.extends(reverse_proxy_for("/api", upstreams)); // plain round-robin across bothMounts one or more upstreams under a URL prefix (the same vpath mounting router uses) and
relays HTTP/1.1 requests/responses verbatim, including a WebSocket upgrade (passed through as a
raw byte splice once the upstream answers 101). For an HTTPS upstream, set use_tls = true
and tls_sni_hostname on the upstream entry (verify_tls_cert defaults to on). Each proxied
request opens a fresh upstream connection — no connection pooling or active health checking yet
(a down upstream fails that one request with 502); see CLAUDE.md's Phase 13 log for the
full list of current simplifications.
Negotiated automatically over plaintext via prior knowledge — no code changes needed beyond
what's already shown above; listener detects an HTTP/2 client connection preface on any
plaintext connection and routes it to the HTTP/2 driver instead of HTTP/1.1:
curl --http2-prior-knowledge http://127.0.0.1:8080/whoamiEvery extension, the router, and reverse_proxy work identically over HTTP/2 with zero code
changes — a stream's request is dispatched through the exact same listener::dispatch() path
HTTP/1.1 uses. ALPN-negotiated HTTP/2 over TLS is not implemented in this round (deferred
alongside a couple of other real scope cuts — request bodies are fully buffered before dispatch,
response headers are assumed to fit in one HEADERS frame, and a few SETTINGS aren't enforced;
see CLAUDE.md's Phase 14 log for the complete, honest list). QUIC/HTTP-3 is not implemented at
all and isn't planned for this project (see CLAUDE.md's architecture-decisions log for why).
Windows is a fully supported, natively-tested target (not best-effort) since the platform layer
was hardened in a dedicated pass — see CLAUDE.md's Phase 12 log for the real bugs found
bringing up the IOCP reactor (a couple of them are genuinely useful "gotchas" for anyone doing
Windows socket programming, not just libnhttp-specific). One real, permanent behavioral
difference from Linux: Windows has no SO_REUSEPORT equivalent, so listener falls back to a
single accept loop that explicitly round-robins connections across workers there (see the
architecture overview above) — functionally equivalent, just not kernel-balanced.
Static-file responses also get a real zero-copy fast path here, same as Linux's sendfile(2):
platform::socket_handle::supports_send_file() is true on Windows too, backed by TransmitFile
over a genuine overlapped I/O completion (Phase 18) rather than the readiness-emulation model this
reactor's plain reads/writes otherwise use — TransmitFile with lpOverlapped == NULL runs fully
synchronously regardless of a socket's blocking mode, so a real completion was the only option that
doesn't block a reactor thread. Measured on this machine: ~5× faster large-file throughput than the
generic read/write fallback it replaces (CLAUDE.md's Phase 18 log has the full numbers and design
story, including why this didn't require redesigning io_context/async_socket around a native
completion model).
Static-file throughput was measured against nginx 1.24, Apache 2.4.58 (event MPM), and a plain
Node.js 20 process (benchmark/docker/node/static_server.js, built-in http/fs only, no
framework or clustering) using wrk, serving an identical
deterministic 10 KB HTML file, 8 threads / 200 connections / 30s. Apache's stock
MaxRequestWorkers (150) was raised to 800 before measuring — the default caps concurrency well
below anything a production deployment would run, and left unraised it produced socket errors
under this load rather than a meaningful number. nhttpd needs no such tuning: every number
below is the untouched library default (blocking_pool_size = 4) — see CLAUDE.md's Phase 16 log
for why a small pool is now better than a large one, the opposite of the advice an earlier round
of this benchmark gave.
Two real bugs in this library were found and fixed while running this benchmark (both now
fixed on main, numbers below reflect the fixed build): a systemic task<T> coroutine-frame leak
on every co_await (~24 KB/request under sustained load), and a SIGPIPE from a client
resetting its connection killing the entire server process. See CLAUDE.md's Phase 15 log for the
full root-cause story of each.
| Server | Req/s | Avg latency | p50 | p99 |
|---|---|---|---|---|
| nginx 1.24 | 140,279 | 3.15 ms | 0.89 ms | 28.98 ms |
| Apache 2.4.58 (event MPM, tuned) | 37,095 | 11.43 ms | 5.47 ms | 97.93 ms |
| Node.js 20 (single process, no clustering) | 4,188 | 54.13 ms | 43.18 ms | 311.51 ms |
| nhttpd (this repo, untuned default) | 61,540 | 4.02 ms | 2.71 ms | 26.35 ms |
nhttpd went from 13.8K req/s (the state this Benchmarks section originally documented) to 61.5K
req/s on this exact benchmark — a ~4.5× improvement, now clearly ahead of both Apache and Node.js,
and at roughly two-fifths of nginx's throughput instead of a tenth of it. This came from a
sendfile(2) fast path for whole-file responses, cutting redundant thread-pool round trips, a
rebuilt lock-free thread_pool job queue (three iterations — two measured as regressions and
reverted before the third one stuck), and a windowed mmap read path for the requests sendfile
can't take (byte-Range, TLS, chunked). blocking_pool_size needs no manual tuning anymore — the
library's own small default is now the fastest setting, the opposite of what this section used to
recommend. Node.js trails every C-based server here by a wide margin — a plain, unclustered node
process is fundamentally single-threaded, so one process can only ever use one CPU core no matter
how many connections arrive, unlike nginx's worker processes, Apache's threaded MPM, or nhttpd's
own multi-worker reactor; a fair Node.js comparison at this concurrency would need the cluster
module or a multi-process reverse-proxy setup, deliberately out of scope for "how fast is one
plain server process." The full account, including what was tried and reverted along the way and
why, lives in CLAUDE.md's Phase 16 log. A Windows equivalent of this fast path (via
TransmitFile, over a real overlapped completion) shipped in Phase 18 — see the Windows section
below and CLAUDE.md's phase log for the design and a real ~5× throughput measurement on that
platform. PLAN.md currently tracks no open performance items.
A same-host, same-kernel loopback benchmark understates real-world overhead: Linux's loopback
interface skips large parts of the normal socket-to-NIC path (no real Ethernet framing, no
driver queueing, and often no checksum work). benchmark/docker/ runs the same four servers as
separate containers on one Docker bridge network, driven by a fifth client container issuing
wrk against each server by its container DNS name — every request crosses a real veth pair and
Linux bridge, the same kernel code paths a real NIC deployment exercises. All server containers
get identical cpus/mem_limit resource caps so none has an unfair advantage.
Reproduce it:
cd benchmark/docker
docker compose build
docker compose up -d bench-nginx bench-apache bench-node bench-nhttp
docker compose run --rm bench-clientResults (4 CPUs / 1 GiB per server container, otherwise identical parameters to the loopback
run above), current main, nhttpd still at its untuned default:
| Server | Req/s | Avg latency | p50 | p99 |
|---|---|---|---|---|
| nginx 1.24 | 59,992 | 5.17 ms | 2.41 ms | 35.12 ms |
| Apache 2.4.58 (event MPM, tuned) | 25,408 | 17.99 ms | 8.19 ms | 144.63 ms |
| Node.js 20 (single process, no clustering) | 3,412 | 66.71 ms | 53.40 ms | 435.54 ms |
| nhttpd (this repo, untuned default) | 44,375 | 5.33 ms | 3.77 ms | 29.50 ms |
Same story as the loopback numbers: nhttpd (11,170 → 44,375 req/s, a ~4.0× improvement) clearly beats Apache and Node.js here too, and sits at roughly three-quarters of nginx's throughput instead of a sixth. Node.js falls even further behind under the extra latency of real network-stack traffic, for the same single-core reason noted in the loopback section above. All server containers stayed up and memory-stable for the full run. A separate memory-stability check from the original three-way run (Phase 16, before Node.js was added to this comparison) found nhttpd using only 4.96 MiB RSS across 13 threads after 1.08M requests, both figures lower than nginx's own (9 processes/threads, 16.96 MiB) and far lower than Apache's (199 processes, 26.93 MiB) — confirming the coroutine-leak fix holds under real containerized network traffic, not just loopback, and that the small default thread/worker counts P1–P4 arrived at are a genuine resource efficiency, not just a throughput number.
Both benchmarks above serve a static file — a case nhttpd optimized heavily for (the sendfile(2)
fast path). This scenario compares a genuinely dynamic endpoint instead: one that reads an integer
out of a file, increments it, writes it back, and responds with the new value, on every single
request. nhttpd's own handler (benchmark/docker/nhttp/bench_counter_main.cpp) does this in
native C++ (offloaded to thread_pool, guarded by a std::mutex); nginx+PHP-FPM and
Apache+mod_php run an equivalent script (benchmark/docker/php/counter.php, PHP 8.3, guarded by
flock()); a plain, unclustered Node.js 20 process (benchmark/docker/node-counter/counter.js,
built-in http/fs only, no framework or dependencies) does the same with synchronous
fs.readFileSync/writeFileSync calls, which block its one event-loop thread for the duration of
the file I/O and so serialize the critical section the same way the mutex/flock() do on the
other two — all four are paying for the same correctness-under-concurrency guarantee, just via
different mechanisms. This is deliberately Docker-only (benchmark/docker/,
--profile scenario3) — there's no loopback variant, since the point is a fair, apples-to-apples
comparison of real server stacks under the same containerized network path used above, not a
raw-syscall microbenchmark.
Reproduce it:
cd benchmark/docker
docker compose build bench-nginx-php bench-apache-php bench-node-counter bench-nhttp-counter
docker compose --profile scenario3 up -d bench-nginx-php bench-apache-php bench-node-counter bench-nhttp-counter
docker compose run --rm bench-client-scenario3Results (4 CPUs / 1 GiB per server container, 8 threads / 200 connections / 30s, same as the scenarios above):
| Server | Req/s | Avg latency | p50 | p99 |
|---|---|---|---|---|
| nginx 1.24 + PHP-FPM 8.3 | 3,182 | 81.76 ms | 56.98 ms | 436.19 ms |
| Apache 2.4 (mpm_prefork) + mod_php 8.3 | 3,269 | 80.11 ms | 50.72 ms | 479.02 ms |
| Node.js 20 (single process, no clustering) | 4,539 | 50.59 ms | 40.13 ms | 294.37 ms |
| nhttpd (this repo, untuned default) | 57,351 | 4.25 ms | 2.87 ms | 25.92 ms |
nhttpd is ~12–18× faster here than any of the other three — a much larger gap than the static-file scenarios, and an expected one: this isn't measuring nginx/Apache/Node's own general request-handling quality so much as the cost of dispatching into an interpreted/single-threaded scripting layer on every request (PHP-FPM's FastCGI round-trip, mod_php's in-process interpreter invocation, or Node's single event-loop thread blocking on synchronous file I/O) versus nhttpd's handler running as plain compiled C++, offloaded to a real thread pool, in the same process that already owns the connection. Node comes closest of the three (no per-request process/interpreter dispatch overhead the way PHP has), but is still fully serialized behind one thread, unlike nhttp's multi-worker reactor. Apache logged 85 socket timeouts and Node 62, both out of roughly 100–140K requests (under 0.1%); nginx+PHP-FPM had none. All four counters were cross-checked after each run to confirm no lost updates under concurrency (every side's serialization mechanism held).
- CONCEPTS.md — the design philosophy and invariants carried forward from the original implementation, and the gaps (multipart parsing, WebSocket frames, TLS) it left open, all since closed in this rewrite.
- USAGE.md — the original implementation's observable usage patterns, used as the spec for "does the new API still let a caller express the same intent."
- docs/protocol-extensibility.md — a review of the design against the architectural seams HTTP/2 needed (all three held unchanged) and QUIC still would.
- PLAN.md — the live to-do list of open performance follow-ups; finished work is
removed from it once done (its history lives in
CLAUDE.md's phase log instead). - CLAUDE.md — the running build/architecture/decisions log for anyone (human or otherwise) picking up work on this repo.
